BitBox Magneti Marelli BENCH-CAN

BitBox Magneti Marelli BENCH-CAN Product Description:

Software Activation From BitSoftware with Product Number: MK27155

BitBox Magneti Marelli BENCH-CAN Specs:

Manufacturer: BitSoftware

Module for reading and writing on the Bench through CAN-bus for diesel and petrol vehicles with Magneti Marelli ECUs.

Attention! It needs to connect ECU on the bench with any adapter with automatic power management (SM2 bench cable, BITS001, Powerbox, etc...)

Magneti Marelli MPC5XXX BENCH-CAN (FID:460)

It allows:

• Software identification
• FullFlash reading
• FullFlash writing
• Flash CS fix on writing
• Recovery
• EEPROM reading and writing

Supported ECU types:

• MJD 8F2 - MPC5565 + 95640
• MJD 8F3 - MPC5565 + 95640
• 8GMB - MPC5565 + 95128
• 8GMC - MPC5565 + 95128
• 8GMF HW503 - MPC5565 + 95640
• 8GMK - SPC564A80 (MPC5644) + 95128
• 8GMW - MPC5565 + 95128
• 8GSW - MPC5565 + 95128
• 8GSF - MPC5565 + 95640
• 9GC - SPC564A70 (MPC5642) + 95640
• 9GF - SPC564A70 (MPC5642) + 95640
• 10JA - MPC5777 + 95128

Magneti Marelli TC277 BENCH-CAN (FID:502)

It allows:

• Software identification
• FullFlash reading
• SOFT+CAL writing
• Flash CS fix on writing
• Recovery
• Int. and Ext. EEPROM reading and writing

Supported ECU types:

• 11GC - TC277 + Internal EEPROM + 95256
• 11GDB - TC277 + Internal EEPROM
• 11GF - TC277 + Internal EEPROM + 95640
• 11MP - TC277 + Internal EEPROM + 95640

Other ECU types will be added by possibilities.

Extra Details:
