Product Description:

Software Activation From Abrites with Product Number: MK25339

Abrites MN038 license allows you the exceptional ability to calibrate IC223 (2020+) and IC177 M (2023+) clusters in Mercedes-Benz vehicles, equipped with Visteon R7F701529 BGA processors. This software license ensures a safer and simpler process, not requiring any work with the EZS (EIS) module - it is neither needed, nor affected during the procedure. Synchronisation between the EZS (EIS) module and the Instrument cluster is blocked via an emulator. All operations are carried out directly on the IC223/IC177 M cluster PCB for maximum efficiency and reliability.

Functionality:

• Adjust the mileage value in the IC223/IC177 M dashboard
• Block the synchronization of the mileage with the EZS module

Supported Models:

• W223 S-Class 2020+
• W206 C-Class Sedan (Saloon) 2021+
• S206 C-Class Station Wagon (T-model) 2021+
• V206 C-Class Long Wheelbase Sedan 2021+
• X206 C-Class All- Terrain 2021+
• X254 GLC 2022+
• C254 GLC Coupe 2022+
• C236 CLE Coupe 2023+
• A236 CLE Cabriolet 2023+
• Other models with the IC223, equipped with Visteon R7F701529 BGA processor

Including models after 2023 with IC177 M, equipped with Visteon R7F701529 BGA processor, such as:

• W177 A-Class
• W243 B-Class
• W247 B-Class
• H243 EQA- Class
• X243 EQB- Class
• C118 CLA- Class
• H247 GLA- Class
• W167 GLE/ GLS- Class
• X247 GLB-Class
• W257 CLS-Class
• X290 AMG GT Four Door Facelift

The procedure requires working with the IC223/IC177 M module's PCB on bench, unsoldering a few capacitors and soldering the wires of the CB501 cable onto it. Wiring diagrams are included within the software for guidance. If alternative wiring is required for specific modules

In order to connect and work with the IC223/IC177 M cluster successfully, you will need the ZN085 RH850/V850Programmer and the ZN092 adapter. The EM019 adapter is required to complete the procedure successfully. After the new value is written with the help of the RH850 Programmer and CB501 cable, unsolder the CB501 wires and solder the EM019 as shown in the user manual.

AVDI with active Annual Subscription is required to use this functionality.
