Abrites PN020 - PIN Manager (BSI and Engine Control Unit)

Abrites PN020 - PIN Manager (BSI and Engine Control Unit) Product Description:

Software Activation From Abrites with Product Number: MK27547

Abrites PN020 - PIN Manager (BSI and Engine Control Unit) Specs:

Manufacturer: ABRITES

The PIN Manager allows you to read the PIN code from the BSI or ECU units and use it to program keys for Peugeot and Citroen vehicles, manufactured after 2016.

Functionalities:

• PIN code reading
• Key programming (HT-AES)
• Emergency start

The PIN code is retrieved by using the ZN094 key emulator, which can consequently be used for emergency start in All Keys Lost situations, in order to start and drive the vehicle to the nearest workshop.
For vehicles 2021+ with BSI the PIN is read directly in seconds even in a case of All Keys Lost It is no longer necessary to read the BSI EEPROM or to read the PIN from the Engine Control Unit!
For vehicles 2022+ with VSM the PIN is read directly in seconds, but a working key is required or VSM EEPROM dump in a case of All Keys Lost.
The new procedure is a much faster, easier and safer solution!

Note: Retrieving the PIN by ZN094 emulator does not bypass 30 minutes waiting time when learning a new key.
