DiagCar FORD AIRBAG TC2XXX CAN Programmer

DiagCar FORD AIRBAG TC2XXX CAN Programmer

Product Description:

Software Activation From DiagCar with Product Number: MK25407

Specs:

Manufacturer: DiagCar

Note:
CPT CAN ADAPTER REQUIRED

FORD AIRBAG INFINEON TRICORE TC22XX-16F CAN PROGRAMMER:

• Without opening
• Without soldering
• Easy connection
• Quick repair

OPTIONS:

• Dflash read/write by CAN
• Pflash0 read / write by CAN
• Read all banks by CAN
• Auto Veryfy by CAN
• Read DTC by CAN
• Erase DTC by CAN

PART NUMBERS LIST:

Ford, Ecosport, , GN15 14B321 AE, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 AF, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 AG, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 BF, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 BJ, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 CF, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 CJ, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 DF, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 DG, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 DH, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 DJ, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 GF, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 GG, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 GH, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 GJ, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 GK, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 HC, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 JC, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 KA, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 KB, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 KC, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 LB, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 LC, TC22xx-16F,
Ford, Ecosport, , GN15 14B321 LD, TC22xx-16F,
Ford, Fiesta, , H1BT 14B321 AF, TC22xx-16F,
Ford, Fiesta, , H1BT 14B321 AG, TC22xx-16F,
Ford, Fiesta, , H1BT 14B321 AH, TC22xx-16F,
Ford, Fiesta, , H1BT 14B321 AJ, TC22xx-16F,
Ford, Fiesta, , H1BT 14B321 BB, TC22xx-16F,
Ford, Transit, , J7BT 14B321 AB, TC22xx-16F,
Ford, Ka, , J7BT 14B321 AC, TC22xx-16F,
Ford, Ka, , J7BT 14B321 AD, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 AD, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 AE, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 BD, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 BE, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 DD, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 DE, TC22xx-16F,
Ford, Ranger, , JB3T 14B321 FA, TC22xx-16F,
Ford, Transit, , JK2T 14B321 AF, TC22xx-16F,
Ford, Transit, , JK2T 14B321 AG, TC22xx-16F,
Ford, Transit, , JK2T 14B321 AH, TC22xx-16F,
Ford, Transit, , JK2T 14B321 AJ, TC22xx-16F,
Ford, Transit, , JK2T 14B321 BF, TC22xx-16F,
Ford, Transit, , JK2T 14B321 BG, TC22xx-16F,
Ford, Transit, , JK2T 14B321 BJ, TC22xx-16F,
Ford, Expedition, , JL1T 14B321 BA, TC22xx-16F,
Ford, Fusion, , JL1T 14B321 BB, TC22xx-16F,
Ford, Fusion, , JL1T 14B321 CA, TC22xx-16F,
Ford, Ranger, , KB3T 14B321 BD, TC22xx-16F,
Ford, , , KK3T 14B321 AC, TC22xx-16F,
Ford, , , KK3T 14B321 BC, TC22xx-16F,
Ford, Transit, , KT1T 14B321 AD, TC22xx-16F,
Ford, Transit, , KT1T 14B321 DD, TC22xx-16F,
Ford, Transit, , KT1T 14B321 GD, TC22xx-16F,
Ford, Transit, , KT1T 14B321 KD, TC22xx-16F,
Ford, Explorer, , LB5T 14B321 PA, TC22xx-16F,
Ford, Transit, , LK4T 14B321 BE, TC22xx-16F,
Ford, Expedition, , LL1T 14B321 AA, TC22xx-16F,
Ford, Expedition, , LL1T 14B321 CA, TC22xx-16F,
Ford, Transit, , LT1T 14B321 AA, TC22xx-16F,
Ford, Transit, , LT1T 14B321 KA, TC22xx-16F,
Ford, Ecosport, , LN15 14B321 BB, TC22xx-16F,
FORD, Ecosport, , GN15 14B321 CH, TC22xx-16F,
FORD, , , KK3T 14B321 CA, TC22xx-16F,
FORD, Transit, , LT1T 14B321 DA, TC22xx-16F,

QUICK INSTRUCTION:

1. Connect Your CPT to PC
2. Connect CPT POWER ADAPTER to CPT
3. Connect CPT CAN ADAPTER to CPT
4. Connect Power Black Box (or external 12V) to CPT CAN ADAPTER
5. Connect airbag module to CPT CAN ADAPTER ( connection diagram available in support area)
6. Run CPT exe and select OBD II in first left menu next other menu section and start read
