DiagCar MAZDA AIRBAG TC2XXX CAN Programmer

Product Description:

Software Activation From DiagCar with Product Number: MK25409

Specs:

Manufacturer: DiagCar

NOTE:

CPT CAN ADAPTER REQUIRED

MAZDA AIRBAG INFINEON TRICORE TC23XX-16F CAN PROGRAMMER:

• Without opening
• Without soldering
• Easy connection
• Quick repair

OPTIONS:

• Dflash Read by CAN
• Dflash Write by CAN
• ECU info by CAN
• Read DTC by CAN
• Erase DTC by CAN

PART NUMBERS LIST:

Mazda, 3, , BCKA-57K30C, TC233LP16F,
Mazda, 3, , BCKA-57K30D, TC233LP16F,
Mazda, 3, , BCKA-57K30E, TC233LP16F,
Mazda, , , BEPN-57K30D, TC23xx-16F,
Mazda, , , BEPN-57K30E, TC23xx-16F,
Mazda, , , BELG-57K30, TC23xx-16F,
Mazda, 6, , GBEF-57K30A, TC23xx-16F,
Mazda, 6, , GBEF-57K30B, TC23xx-16F,
Mazda, 6, , GBEF-57K30F, TC23xx-16F,
Mazda, 6, , GBFT-57K30A, TC23xx-16F,
Mazda, 6, , GBFS-57K30A, TC23xx-16F,
Mazda, 6, , DFR5-57K30, TC23xx-16F,
Mazda, 6, , DFR5-57K30A, TC23xx-16F,
Mazda, 6, , DGS9-57K30, TC23xx-16F,
Mazda, 6, , DGS9-57K30A, TC23xx-16F,

QUICK INSTRUCTION:

1. Connect Your CPT to PC
2. Connect CPT POWER ADAPTER to CPT
3. Connect CPT CAN ADAPTER to CPT
4. Connect Power Black Box (or external 12V) to CPT CAN ADAPTER
5. Connect airbag module to CPT CAN ADAPTER ( connection diagram available in cpt software and in support area)
6. Run CPT exe and select OBD II in first left menu next other menu section and start read
