Product Description:

Software Activation From I/O TERMINAL with Product Number: MK6793

Specs:

Manufacturer: I/O Terminal

This PSA BSI I/O Terminal tool plugin can offer functions that normally would normally require the ECU to be opened and a BDM/Boot programmer connected, however, it can accomplish these procedures without opening the ECU and in some cases all from OBD.

Using this tool you gain full control of the ECU’s memories.

You can read/write EEPROM and internal/external flash memories (where available)

All operations are done over K-line or CAN bus without the need to open ECU!

Bench read/write only!

Supported PSA BSI ECU’s:

1. Siemens D76F0018+95160 KLINE (BSI-E0X-00/BSI-F0X-00) – EEPROM 95160 R/W , show PIN
2. Siemens 1L00M+95128/95256 CAN (BSI-S0X-00) – EEPROM 95128/95256  R/W, show PIN, 9S12DP512 FLASH R/W
3. Continental SC667050+95256 CAN (BSI-Q0X-00) – EEPROM 95256 R/W, show PIN, SC667050 FLASH R/W
4. Valeo 4L00M+95128/25128 CAN (BSI2004-P0X-00) – EEPROM 95128/25128 R/W, show PIN, 9S12DP512 FLASH R/W
5. Valeo 2M48H+24C128 CAN (BSIEV-X0X-00) – EEPROM 24C128 R/W, show PIN, 9S12XEP768 FLASH R/W
6. Valeo SC667152+95256 CAN (BSI-N0X-00) – EEPROM 95256 R/W, show PIN, SC667152 FLASH R/W
7. Johnson Controls easyCAN4+29LV400+95128 CAN (BSI2004-H0X) – EEPROM 95128 R/W, show PIN, 29LV400BB FLASH R/W
8. Johnson Controls easyCAN4F1M-32+95128 CAN (BSI04EV-K0X) – EEPROM 95128 R/W, show PIN, easyCAN4F1M-32 FLASH R/W
9. Johnson Controls SPC560B60+95128 CAN (BSI04EV2-KEX) – EEPROM 95128 R/W, show PIN,SPC560B60 FLASH R/W
