ODIS Engineering Software V.17

Product Description:

Software Activation Online Services From ODIS with Product Number: MK17278

What is ODIS Engineering Software V.17 ?

ODIS software is diagnostic software for technicians, with the following information

If you have a part that is non-programable due to the files on it are mismatched with the vehicle, then this software allows you to reflash the file on that part in order to program it for that vehicle.

ODIS Engineering Software V.17 Multi-language Support:

English / Japanese / Portuguese / Romanian / Korean / Dutch / Polish / Turkish / Spanish / French / Italian / Croatian / Danish / English German / Swedish / Finnish / Slovene / Czech / Russian / Greek Greek / Chinese.

ODIS ENGINEER 17 is a specialized programming and diagnostic software, supporting until 2023-2024 for Audi, Volkswagen, Bentley, Skoda, Seat, MAN, Lamborghini, Bugatti brands

ODIS Engineer (Information Systems Engineering, Offline Software) is the setup for the vehicles of the VAG group. With compatibility with the standard diagnostic device SAE J2534, this software enables offline ECU diagnosis, encoding, and installation on Volkswagen, Volkswagen Nutzfahrzeuge, Audi, Skoda, Seat, MAN, Lamborghini, Bentley, and Bugatti.

ODIS Engineering Software V.17 System requirements for the Offboard Diagnostic Information System software

The Offboard Diagnostic Information System software is the programm that provides you with an interface that complies with SAE J2534 (diagnostic interface). With this software it is possible to diagnose all vehicles from Volkswagen Group lmport (China) Co., Ltd..

The following requirements must be met in order to operate the Offboard Diagnostic Information System software:

• Operating system: Microsoft®  WIndows11 (64 bit)
• CPU: at least 2 Ghz, recommended: 2.5 GHz dual-core processor
• RAM: at least 4 GB, activated virtual memory
• Hard drive: at least 75 GB free memory.
• Graphics: at least 800 x 600, recommended: 1024 x 768
• Miscellaneous:
  • One free USB port for the diagnostic interface
  • Online connection

ODIS ENGINEER Software V.17 has the following functions:

the Volkswagen Group Offline Diagnostic Information System Engineering software is used in technical diagnostics. It allows to define vehicle control units and read entries in memory. The software also supports vehicle repair using flash controllers and troubleshooting guides. Functions such as test device support, flash programmable controller and vehicle self-diagnosis will help to expand the range of applications.

• Read Error.
• Clear Error.
• Basic Setup.
• Flash ECU Offline.
• Code.
• Field Measures.

ODIS Covered Brands:

1. VW
2. AUDI
3. SEAT
4. SKODA
5. LAMBORGHINI
6. BENTLEY
7. M.A.N VANS

VW VAG vehicle communication interfaces (VCI)

1. VAS 6154 ( ALLScanner VCX-DoIP  ALLScanner VCX  ALLScanner VCX NANO  )
2. Autel passthru
3. Openport passthru
4. Scanmatik

The newer VAS6154 has many feature not present in the VAS5405A/B

For example VAS 6154 Support VAG vehicles from 2000 onward including
New & future models still under production.

The VAS 6154 Interface is the latest interface for the diagnostic and programming applications VAG ODIS-S (Service) and ODIS-E (Engineering), it replaces the VAS 5054A

ALLScanner VCX-DoIP

ALLScanner VCX SE

ALLScanner VCX NANO for Volkswagen USB / WIFI

VAS6154 Infrastructure mode:

In infrastructure mode, several network-capable devices can be connected together (network subscribers).
For a wireless network, a WLAN access point is required. This access point forms the connection to WLAN-ready subscribers.

VAS6154 Point-to-point connection:

With point-to-point connection via a wireless network, VAS 6154 creates a radio network. VAS 6154 thereby adopts the role of a radio access point (Access Point).
A direct connection is made between the diagnosis unit and the diagnosis interface VAS 6154.
VAS 6154 is configured using the web-based user interface.

Autel MaxiFlash passthru

As a multi-protocol Pass-Thru vehicle interface, MaxiFlash Elite is a fully compliant SAE J2534-1 & SAE J2534-2 (March 2006) device. Specially designed to provide users with convenient PC communication and ECU reprogramming capabilities on any modern vehicle diagnostic bus, MaxiFlash Elite offers the most significant features desired by OEM customers: reliability, fast performance and flexibility.

 OpenPort PassThru:

The OpenPort 2.0 is the newest tuning hardware from Tactrix that is capable of communicating with a most OBDII compliant vehicles using a standard J2534 int. Combined with Tactrix EcuFlash software, the OpenPort 2.0 is capable of reflashing a large number of newer vw vehicles, and support for other cars is in progress.

 Scanmatik:

Professional multi brand auto scanner designed to diagnose electronic control systems of modern cars. Works with a personal computer, tablet or smartphone, programs for Windows and Android included.

ODIS Version Comparision:
